Self Lubricating Bushing | Focus Hydraulics Industry

JIAXING VIIPLUS INTERNATIO NAL TRADING CO.,LTD
Contact Now

Self Lubricating Bushing | Focus Hydraulics Industry

Brand Name : Straight Sleeve Bore Bushings

Model Number : sleeve Bushing Applications include valves, commercial fire sprinkler systems, mixers, blenders, swivels, and extruders.

Certification : wrapped bushing, Bronze Steel self-lubricatging bushing, DIN 1494 / ISO 3547, Low-maintenance

Place of Origin : Valve Bushing Manufacturer

MOQ : 100 Piece/Pieces (Min. Order)

Price : Negotiable

Payment Terms : TT IN ADVANCE

Supply Ability : Valve Split Steel Bushings Shaft Bearings Suppliers

Delivery Time : 1~2 WEEKS

Packaging Details : Export standard packing

Meterial : Carton steel , Bronze , STRIPS

Plating : Tin or copper

Type : Sheet

Customized : Available as per drawing

Special Use : High-strength Steel Plate

Features : Wear,Dry,Low Resistance

Port : ShangHai

Application : Hydraulic system cylinder

Bearing Bushing Factory Price : tiffany@viiplus.com

Self-lubricating Bearing Bushing Manufacturer : https://www.viiplus.com/

High Light : Valve bushings suppliers

self-lubricating, metal-polymer plain bearing : Metal-Polymer Anti-Friction Plain Bearings

Bush Bearings Manufacturers Suppliers Exporters : plain bearings. Long, maintenance-free service, manufactures bushings in various designs and from different materials. tiffany@viiplus.com, Bushings - Configure and purchase - https://www.viiplus.com/

Contact Now

Self-lubricating bushings are a crucial element in the hydraulics industry, playing a vital role in ensuring the smooth and efficient operation of hydraulic systems. These bushings are designed to provide long-lasting lubrication, reducing friction and wear, which can lead to increased system performance and durability.

The self-lubricating feature of these bushings eliminates the need for regular lubrication, making maintenance easier and reducing operational costs. This feature is achieved through the use of special materials or coatings that naturally release lubricant as they operate.

The hydraulics industry relies heavily on precision components to handle high-pressure fluids, and self-lubricating bushings are an excellent choice for such applications. They can be found in various hydraulic systems, including pumps, valves, cylinders, and other critical components.

By focusing on hydraulics industry needs, manufacturers of self-lubricating bushings can provide customized solutions that meet specific performance requirements. This ensures that the bushings integrate seamlessly into the hydraulic system, delivering optimal performance and reliability.

In summary, self-lubricating bushings are an essential component in the hydraulics industry, enabling efficient and durable fluid handling while reducing maintenance requirements. By focusing on industry needs, manufacturers can provide tailored solutions that meet the unique challenges of hydraulic systems.

Self Lubricating Steel Backed Bronze Bushing | Focus Hydraulics Industry

Cylindrical Sliding Bushings- Bearing & Bushings, Supplier of Hydraulic Bush - Hydraulic Bushing, Hydraulic Cylinder Bush offered by www.viiplus.com

Hydraulic System Cylinder Valve Bushing, Self Lubricating Bearings

VIIPLUS Self-Lubricating Bearings Material provides high-end casting to our valve divisions including materials like (low temperature) carbon steel/ stainless steel/ Bushing POM Bushes and high bronze alloy steels bearings.All analyses regarding the mold and pattern designs are being performed in our own premises in order to guarantee a constant casting level and quality.

Self-Lubricating Bearings Hydraulic system cylinderbushing | VSB-40Self Lubricating Bushing | Focus Hydraulics Industry

Auto transmission parts automobile steering system flange bushing and bearings for sale




VSB-40 Metal-Polymer Low Friction Plain Bearings

Detailed information

Sf-1d hydraulic special bearing. Is on the basis of SF, 1 p combined with the oil cylinder and the working principle of the shock absorber and design a new type of material, under the condition of no oil is wear-resisting, in addition to the product has the advantages of SF, 1 d, especially suitable for reciprocating frequent occasions large lateral force. Its performance is similar to that of Metal-Polymer Low Friction Plain Bearings, which is gradually replacing sf-1p products, which can be used in automotive, motorcycle shock absorbers and various hydraulic cylinders.



VSB-40 Metal-Polymer Low Friction Plain Bearings low friction bushings offer good wear and low friction performance over a wide range of loads, speeds and temperatures in dry running conditions
· Very good performance in lubricated applications
· Good performance in greased applications
· Suitable for linear, oscillating and rotating movements

Suitable for dry running, low coefficient of friction, lower wear, good sliding characteristics, the transfer film created can protect the mating metal surfaces, suitable for rotating and oscillating movement, high chemical resistance, low absorption of water and swelling. The VSV-40 improved the friction and much good wear resistance over the common CSB-10 range under lubricated operation.

STRUSTURE


1. /Polymer fibres mixture thickness 0.01~0.03mm. Lead-free bearing layer provides an excellent initial transfer film, which effectively coats the mating surfaces of the bearing assembly, forming an oxide type solid lubricant film.

2. Sintered bronze powder thickness 0.20-0.35mm, provides max. thermal conductivity away from the bearing surface, also serves as a reservoir for the mixture.

3. Steel backing, provides high load carrying capacity, excellent heat dissipation.

4. Copper/Tin plating thickness 0.002mm, provides good corrosion resistance.

5. Steel + Bronze Powder + /Fibre(Metal-Polymer Low Friction Plain Bearings)

TECHNICAL DATA


STRUCTURE & COMPOSITION

· Metal-Polymer Composite Bushing Material
· Steel back + Porous Bronze Sinter +
· + Fillers

MICROSECTION

Self Lubricating Bushing | Focus Hydraulics Industry

Sliding layer
+ Fillers
Porous Bronze Sinter
Steel Backing


Tech. Data

Max. load Static 250N/mm2 Max.speed Dry running 0.08~0.20
Very low speed 140N/mm2 Hydrodynamicoperation 0.02~0.08
Rotatingoscillating 60N/mm2 Frictioncoefficient Dry 2m/s
Hydrodynamic >2m/s
Max. PVdryrunning) Short-termoperation 3.6N/mm2*m/3 Thermal conductivity 42W(m*K)-1
Continuousoperation 1.8N/mm2*m/3
PV max. hydrodynamic -195℃~+280℃ Coefficient of thermalexpansion 11*10-6*K-1

Self Lubricating Bushing | Focus Hydraulics Industry

OPERATING PERFORMANCE
Dry Good
Oil lubricated Very Good
Grease lubricated Good
Water lubricated Fair
Process fluid lubricated Good

BEARING PROPERTIES

GENERAL

Unit

Value

Maximum load, p

Static
Dynamic

N/mm2
N/mm2

250
140

Operating temperature

Min
Max

°C
°C

- 195
280

DRY
Maximum sliding speed, U m/s 2.0
Coefficient of friction 0.03 - 0.20 *

OIL LUBRICATED
Maximum sliding speed, U m/s >2.0


* Depending on operating conditions

Technical data

Max. load Static 250N/mm2
Dynamic 140N/mm2
Max. speed Dry 2m/s
Lubrication >2m/s
Max. PV (Dry) Short-time 3.6N/mm2*·m/s
Continuous 1.8N/mm2*·m/s
PV Hydrodynamic 30N/mm2*·m/s
Temp. -195℃~+280℃
Friction coefficient 0.03~0.20
Thermal conductivity 42W (m·k)-1
Coefficient of thermal expansion 11*10-6k-1

AVAILABILITY


Bearing forms available in standard dimensions
· Cylindrical bushes
· Flanged bushes
· Sliding plates
· Thrust washers
· Flanged washers

Self Lubricating Bushing | Focus Hydraulics IndustrySelf Lubricating Bushing | Focus Hydraulics IndustrySelf Lubricating Bushing | Focus Hydraulics IndustrySelf Lubricating Bushing | Focus Hydraulics IndustrySelf Lubricating Bushing | Focus Hydraulics Industry

Metric bearings and imperial bushings made to order: Standard bushing forms in special sizes, half-bushings, stamped/deep drawn shapes, bearings with locating notches, lubricant holes and grooves, customized designs

TYPICAL APPLICATIONS



VSB-40 is developed for high duty, oil lubricated, hydraulic applications...Automotivesuspensionstruts,absorbers guide bushing, hydraulic cylinders, gear pumps, motors, axial and radial piston pumps & motors.VSB-40 is designed mainly for using under lubricated conditions and it performs excellent wear resistance and low static/dynamic shockfriction coefficient.



Self Lubricating Bushing | Focus Hydraulics Industry

BUSHINGS SIZE



START YOUR
PROJECTWITH AN APPLICATION ENGINEER

Bushings,Lubricated Bearings,Composite Bearings,Metal Bearings,Compressor Bearings,Metal-polymer,Filament Wound,Plain Bearings,Flange Bearings,Polymer Bearings,Flange Bushings,Pump Bearings,Flanged Bushes,Thrust Plates,Industrial Bearing
