Self-Lubricated Bronze Oilless Graphite Washers Anti-Friction are a unique type of washer designed to provide friction-free operation without the need for traditional lubrication. These washers are made from a combination of bronze and graphite, creating a material that is both strong and self-lubricating.
The bronze component of the washer offers excellent durability and resistance to wear, making it suitable for high-load and high-speed applications. The graphite, on the other hand, acts as a natural lubricant, reducing friction and heat generation during operation. This self-lubricating property eliminates the need for regular lubrication, reducing maintenance requirements and downtime.
The anti-friction design of these washers ensures smooth and efficient operation, even in demanding conditions. They are ideal for use in a wide range of industrial applications, including pumps, motors, gearboxes, and other rotating or reciprocating equipment.
In summary, Self-Lubricated Bronze Oilless Graphite Washers Anti-Friction offer a robust and reliable solution for reducing friction and wear in industrial applications. Their combination of strength, durability, and self-lubricating properties ensures smooth and efficient operation, reducing maintenance costs and improving overall equipment performance.
BG1 Bushes Graphite Bronze Bushings Anti Friction Thrust Washers
Offer reliable and economical solutions, Self Lubricated Bronze & Graphite Embedded Bushing BG1 Bushes Graphite bronze bushings. BG1 Thrust washers and Anti-friction Washers, self-lubricating Bronze bearings & Bushings Catalog Oil Free Bushings. Since bearings usually receive a lot of frictional resistance that generates heat, lubricants such as oil Bushings & Bearings - Sleeve, Flange, Thrust
- Graphite Plugged Bearing : Achieving excellent self-lubrication and abrasion resistance under dry lubricating condition with graphite.
| Type | Description |
| | |
| BG1 Bushes | 50x65x40 |
| 50x65x45 |
| 65x80x50 |
| 80x100x70 |
| 65x80x70 |
| 65x80x80 |
| 80x100x80 |
| | |
| BG1 Trust washers | W65 |
| W80 |
| | |
| Anti frcition Washers | 5mmx50x100 |
| 5mmx65x120 |
| 5mmx80x120 |
Manufacturer Of Bushings - bronzegleitlager.com, bronze bushing with graphite - online sale
Graphite plug is embedded into a metal part, solid bronze graphite Self Lubricating bushing ...
Self Lubricating, Graphite Embedded, Oilless Bearings.
Find graphite plate companies that can design, engineer, and manufacture graphite wear plates to your companies specifications.
Self Lubricating Bushes Manufacturer from China
Oilless Bush - Self Lubricating Bush & Guide Bush, WEAR PAD
Self-lubrication with specially embedded solid lubricants reduces friction.
Solid lubricant inlaid bush bearing use High-grade Metal Alloy as their base material, Inlaid Graphite and grease during the process of friction, will release solid lubricant and lubricant oil automatically. Self Lubricated Bronze & Graphite Embedded guide bushing & WEAR PAD bearing widely used in Injection Moulding Machines, Automobile Moulds, Food Machinery, Water Turbines, Engineering Machinery etc.
Graphite Embedded Bronze Bush
Dimensional accuracy
Typical dimensional tolerances
Bronze metal components
| Material | ZCuZn25AI6Fe3Mn3 |
| Brand | Self Lubricated Bronze & Graphite Embedded Bearings |
| Usage/Application | Industrial / Automobile |
| Size/Diameter | 8 mm to 500 mm |
| Shape | Cylindrical |
| Maximum Load Capacity | 100 N/mm2 |
| Alloy Hardness | >210 HB |
| Coefficient of Thermal Expansion | 15 x 10-6 C |
| Friction Coefficient | Oil - 0.03 and Dry - 0.16 |
| Maximum PV Value Limit | 200 N/mm2 .m/min |
| Density | 8.0 g/cm3 |
| Tensile Strength | >750 N/mm2 |
| Elongation | >12 % |
| Maximum Temperature Limit | 450 Degree C |
Manufacturing process
Bushing metal manufacturing Self Lubricated Bronze & Graphite Embedded Bushing
A Self-Lubricating Bronze Bushing Is A Metallic Component With High Porosity.
Made to Order Copper Alloys Bushing- BearingBronze And Metals Bushing
Bronze Bushings Available - Order Today - BronzeLube.com
Can Economically Make Custom Bushings In Just About Any Size? Made in China
Copper Alloy Bushings, Plates & Parts Specialists For Manufacturing & Machining Of All Types. viiplus.com Saves You Time & Money In Research, Design & Production Costs. E-mail...
Bushings and Bearings - Cast Bronze Oilless bearing
We Are a Streamlined Operation That Utilizes the Speed and Efficiency of an Online Outlet. We Offer Our Vast Inventory of High-Quality Bronze Bearing and Bushings. Order Online.
Professional Flat plain bearing OILES 500 Manufacturer. All Types & Competitive Price. Professional Service. Reasonable Price. Deliver On Time. Strict Quality Control. Self-lubricating Sliding/Plain Bearings Replacement part for Misumi America
Flange plain bearing oiles 500 Metal Bearing
Bearing Bushing Stock -
, INA, -oilless misumi and more. Get a quote/sample. Learn more now.
Self-lubricating bearings for middle loads composed of cast bronze bases and embedded solid lubricant.
Flat Plain Bearings
Self lubricating bearings that can be used oil free. Demonstrate high performance at high load/low speed motion.
oiles bushings
DESCRIPTION
The OILES 500 range of products feature a high-strength brass base with plugged solid lubricants bearing. This line of products includes: OILES 500SP Bushing (internal diameter 6 to 45), SPB OILES 500SP Bushing (internal diameter 50 to 200), SPB OILES 500SP SL-4 bushing, SPBL OILES 500SP flange bushing, SPF OILES 500SP thrust and journal bushing, SPFG OILES 500SP thrust washer, SPW OILES 500SP flange guide bushing, SGF OILES 500SP guide bushing, SGB OILES 500SP guide post, MGP OILES 500SP ware plate (general purpose type), SWP OILES 500SP flat plate material, SFP OILES 500SP plate and Type L SLP OILES 500SP slide core guide rail designed for additional machining. The SLI OILES 500 SP1 features self-lubrication and represents a bearing designed specifically for applications involving heavy loads. It features a high strength brass alloy base, manufactured using advanced casting method that embeds the proprietary solid lubricant.
Flat plain bearing OILES 500
CHARACTERISTICS
| Type | flat |
| Material | bronze |
| Other characteristics | self-lubricating |
Cast Bronze Metric Plain Sleeve Bearing
Bronze with insert solid lubricant material. graphite plugged bronze bushings
Graphite Plugged Bushings are a complete line of Self-Lubricating Bushings that excel whenever standard lubrication is impractical, including heavy load, high-temperature applications. They are manufactured from a variety of Bronze Alloys, including C95400 Aluminum Bronze, C93200 Bearing Bronze, and C86300 Manganese Bronze.
Copper Graphite Bushings and Bearings, buje de bronce Get the best price and read about the company.
bujes de bronce autolubricados
Graphite Plugged Brass Bush Alloy materials
| Model | JDB-1 | JDB-2 | JDB-3 | JDB-4 | JDB-5 |
Grade
China Brands
GB1776-87 | ZCuZn25
AI6Fe3Mn3 | ZCuSn6Zn6Pb3 | ZCuAI10Fe3 | ZCuSu10P1 | Steel+ZCuSn6Zn6Pb3 | HT250 | GCr15 |
International
ISO1338 | GCuZn25
AI6Fe3Mn3 | GCuSn6Zn6Pb3 | GCuAI10Fe3 | CuSn12 | Steel+CuSn6Zn6Pb3Fe3Ni5 | - | B1 |
Germany
DIN | G-CuZn25
AI5 | GB-CuSn5Zn5Pb5 | GB-CuAI10Ni | GB-CuSn10 | Steel+CuSn6Zn6Pb3Ni | - | 100Cr6 |
Japanese
JIS | HBsC4 | BC6 | AIBC3 | BC3 | BC6 | FC250 | SUJ2 |
United States
ASTM/UNS | C86300 | C83600 | C95500 | C90800 | C83600 | Class40 | 52100 |
| British Standard | HTB2 | LG2 | AB1 | PB4 | LG2 | - | - |
Material alloy chemical composition
| Chemical Elements | JDB-1 | JDB-2 | JDB-3 | JDB-4 | JDB-5 |
| Cu ( % ) | Rest | Rest | Rest | - | - |
| Sn ( % ) | - | 6 | - | 10 | 6 | - | - |
| Zn ( % ) | 25 | 6 | - | - | 6 | - | - |
| Ni ( % ) | - | - | - | - | - | - | - |
| AI ( % ) | 6 | - | 10 | - | - | - | - |
| Fe ( % ) | 3 | - | 3 | - | - | Rest | Rest |
| Mn ( % ) | 3 | - | - | - | - | 0.905 - 1.3 | 0.20 - 0.40 |
| Cr ( % ) | - | - | - | - | - | - | 1.30 - 1.65 |
| C ( % ) | - | - | - | - | - | 2.5 - 4 | 0.95 - 1.05 |
| Si ( % ) | - | - | - | - | - | 1.0 - 1.3 | 0.15 -0.35 |
| Pb ( % ) | - | 3 | - | - | 3 | - | - |
Technical Parameters
| Performance | JDB-1 | JDB-2 | JDB-3 | JDB-4 | JDB-5 |
| Max.load P ( N/mm² ) | 100 | 60 | 70 | 60 | 250 |
| Max.speed V ( m/s ) | Dry0.4 oil5 | 2 | 2 | 0.5 | 0.1 |
| Max.PV ( N/mm²·m/s ) | 3.8 | 0.5 | 0.6 | 0.8 | 2.5 |
| Density ρ( g/cmsup3 ) | 8.0 | 8.0 | 7.6 | 7.3 | 7.8 |
| Tensile strength ( N/mm² ) | > 600 | > 250 | > 500 | > 250 | > 1500 |
| Elongation ( % ) | > 10 | > 4 | > 10 | - | - |
| Hardness ( HB ) | > 210 | > 80 | > 80 | > 160 | HRC> 55 |
| Max.temp ( ℃ ) | 300 | 350 | 300 | 400 | 350 |
| Friction coef. ( μ ) | Oil lubrication: 0.03 | Friction(dry): 0.16 |
